big lpg forklift 6 ton dual fuel forklift for sale
The specification of 6 ton Gasoline/LPG forklift
Product Features
1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.
2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.
3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.
4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.
5.Environmental:
Middle muffler, more environmental.
6.High technology:
Maintenance free radiators adopt Germany technology.
Packaging and shipping
LTMG Factory
LTMG Clients
After sales service
The specification of 6 ton Gasoline/LPG forklift
| General | 1 | Model | FG60 | |||
| 2 | Power type | LPG | ||||
| 3 | Rated Capacity | kg | 6000 | |||
| 4 | Load centre | mm | 600 | |||
| Characteristic&Dimension | 5 | Lift Height | mm | 3000 | ||
| 6 | Fork Size | L×W×T | mm | 1220×150×60 | ||
| 7 | Mast title Angle | F/R | Deg | 6°/12° | ||
| 8 | Front Overhang (Wheel center to fork face) | mm | 590 | |||
| 9 | Ground clearance (Bottom of mast) | mm | 200 | |||
| 10 | Overall Dimension | Length to face of fork (without fork) | mm | 3450 | ||
| 11 | Overall width | mm | 2010 | |||
| 12 | Mast Lowered Height | mm | 2550 | |||
| 13 | Mast Extended Height (with backrest) | mm | 4380 | |||
| 14 | Overhead Guard Height | mm | 2470 | |||
| 15 | Turning Radius (outside) | mm | 3250 | |||
| 16 | Min. intersecting aisle | mm | 2960 | |||
| Performance | 17 | Speed | Travel(no load) | km/h | 30 | |
| 18 | Lifting(full load) | mm/s | 500 | |||
| 19 | Max Gradeability | % | 20 | |||
| Chassis | 20 | Tire | Front | 8.25-15-14 PR | ||
| 21 | Rear | 8.25-15-14 PR | ||||
| 22 | Wheelbase | mm | 2250 | |||
| 23 | Service Weight | kg | 9150 | |||
| Power&Transmission | 24 | Battery | Voltage/Capacity | V/Ah | (12V/80AH) × 2 | |
| 25 | Engine | Model | GM4.3L | |||
| 26 | Manufacture | GM | ||||
| 27 | Rated output/r.p.m. | kwt/r.p.m | 56/2200 | |||
| 28 | Rated torque/r.p.m. | N·mt/r.p.m | 240/750 | |||
| 29 | No.of Cylinder | 6 | ||||
| 30 | Bore×Stroke | mm | 101.6×88.39 | |||
| 31 | Displacement | cc | 4300 | |||
| 32 | Fuel Tank Capacity | L | 140 | |||
| 33 | Transmission | Type | Hydraulic | |||
| 34 | Stage | FWD/RVS | 2/2 | |||
| 35 | Operating pressure for attachment | Mpa | 19 | |||
Product Features
1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.
2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.
3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.
4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.
5.Environmental:
Middle muffler, more environmental.
6.High technology:
Maintenance free radiators adopt Germany technology.
Packaging and shipping
LTMG Factory
LTMG Clients
After sales service
LTMG always treat after-sale service more important than sale.
Nowadays more than 30 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
